Introduction:
Use：marble and granite stone cutting machine
It adopts large-area contacting rails and double hydraulic cylinder up-and-down movement to improve the moving up speed. Overall protection of this machine has greatly enhanced stability of the machine to make sure the higher efficiency, longer life-span and lower maintenance rate.
Parameters:
| Name | Unit | GHZJ-1600 | ||||
| No. of blades | pcs | 12 | 16 | 20 | ||
| (6-1600,6-940) | (8-1600,8-940) | (10-1600,10-940) | ||||
| Blade vertical stroke | mm | 1000 | ||||
| Main motor power | kw | 65 | 90 | 110 | ||
| Water consumption | m3/h | 16 | ||||
| Max. cutting size | mm | 3500×1300×650 | ||||
| Dimensions（L×W×H） | mm | 8500×4700×5500 | ||||
| Weight | kg | ≈9000 | ||||
Display:
Video:
